Key Features
- UHD 4K30 Video Capture
- 1/2.8" CMOS Sensor, 1.98mm Focal Length
- SD Card Slot for Recording Capture
- Can Add Logos, Titles, Scoreboards
- Output via Micro-HDMI & USB-A
- 4G LTE Bonding with 2 SIM Slots, Wi-Fi
- 3" Touchscreen, App/Browser Control
- 3.5mm Stereo Analog Audio Input/Output
- General Details
- Specification
- Product Enquiry
Capture, record, and livestream from any location with the A5 4K Streaming Camera with 4G Bonding from MiNE Media. This professional camera can capture stunning video with up to UHD 4K resolution and output via HDMI, USB for streaming, Wi-Fi, or via optional 4G LTE SIM cards. The camera features two SIM slots that can bond with the Wi-Fi connection to transmit simultaneously to redundant destinations. The camera also allows you to add logos, titles, and even scoreboards for event production, live broadcasts, and sporting events.
The compact camera features a 1/2.8″ Sony CMOS sensor for crystal-clear imagery, and it features a fixed lens with a 1.98mm focal length for a wide angle with sharp focus on the entire scene. The camera also features a 3.5mm stereo analog audio input and output, so you can add audio to your capture or output audio to headphones, a mixer, or speakers. You can also record your streams using the built-in SD card slot.
Outputting your video locally is made easy with a micro-HDMI output, as well as a USB output to connect to a local computer for additional web streaming options via an app. A 3″ touchscreen on the back allows you to control the camera’s settings, and you can also control the camera via a browser or mobile app using a Wi-Fi connection.
Key Features at a Glance
1/2.8″ Sony CMOS sensor
1.98mm focal length
Up to 2160p30 streaming and recording
3″ touchscreen interface
4G LTE bonding with two built-in SIM slots and Wi-Fi
SD/TF card slot for recording
3.5mm stereo audio input and output
Micro-HDMI output
USB-A port for additional network connection
Browser and mobile app control
Add logos, titles, and scoreboards
Items Included
- MiNE Media A5 4K Streaming Camera with 4G Bonding
- Limited 1-Year Manufacturer Warranty
| Image Sensor | 1/2.8″-Type |
| Effective Sensor Resolution | 8 Megapixel |
| Max Recording Modes | AVCHD/H.264/H.265 Up to UHD 4K at 23.98/29.97 fps |
| Max Video Output | No |
| Media/Memory Card Slot | Single Slot: SD/SDHC/SDXC |
| Video I/O | USB-A / Micro-HDMI |
| Mobile App Compatible | Yes: Android & iOS |
| Battery | Built-In Lithium-Ion |
Imaging
| Image Sensor | 1/2.8″-Type CMOS |
| Effective Sensor Resolution | 8 Megapixel |
Lens
| Focal Length | 1.98mm |
Focus
| Focus Mode | Fixed Focus |
Video Capture
| Internal Recording | AVCHD/H.264/H.265 3840 x 2160 at 23.98/29.97 fps (20 Mb/s) 1920 x 1080p at 23.98/29.97/50/59.94 fps |
| Video Output | No |
| Interval Recording Modes | No |
| Audio Recording | 2-Channel at 48 kHz via AAC Audio |
| IP Streaming | RTMPS, SRT 3840 x 2160 at 25p, 30p 1920 x 1080 at 25p, 30p, 50p, 60p to |
Interface
| Media/Memory Card Slot | Single Slot: SD/SDHC/SDXC |
| Internal Storage | No |
| Video I/O | 1x Micro-HDMI Output 1x USB-A 2.0 Output |
| Audio I/O | 1x 1/8″ / 3.5 mm TRS Stereo Mic/Line Input 1x 1/8″ / 3.5 mm TRS Stereo Headphone/Line Output |
| Power I/O | 1x USB-C Input |
| Wireless | Wi-Fi |
| Mobile App Compatible | Yes: Android & iOS |
Monitor
| Display Type | Primary Monitor: Fixed 3″ Touchscreen LCD |
Power
| Battery | Built-In Lithium-Ion |
| Power Consumption | 8 W |
Environmental
| Operating Conditions | 32 to 104°F / 0 to 40°C |
General
| Dimensions (W x H x D) | 5.1 x 3.1 x 2.4″ / 130 x 80 x 60 mm |
| Weight | 14.1 oz / 400 g (Body Only) |
Packaging Info
| Package Weight | 1.41 lb |
| Box Dimensions (LxWxH) | 6.7 x 5 x 4″ |
